Oil Filling Machine
Salient Features:
- ± 1% Filling accuracy on a single dose.
- No bottle, No filling system.
- Rigid vibration free construction for trouble-free performance.
- S.S. Elegantly matt finished body.
- Elegant and comfortable control panel for total control of the operation.
- Minimum changes over time, from one size to another container or fill size.
- Self-lubricating UHMW-PE guide profile for S.S. slat chain provides low friction wear surface, smooth and noiseless conveying.
- Error code display on A.C. frequency drive on the control panel.
- Drain tray around machine platform.
- Drip tray under the conveyor.
- Pneumatic bottle stopping arrangement.
