Tablet Inspection Belt
Salient Features:
- All contact parts are made of stainless steel or synthetic materials such as nylon, ensuring non contamination.
- Nylon endless conveyor belt, apart from having long life, is also washable and easily replaceable type.
- Both conveyor speed and tablet feed are adjustable.
- Extra large hopper for less frequent fillings, with a holding capacity of about 25 to 30 Kg.
- Hopper position is vertically adjustable with a knob.
- Level in the hopper is easily visible to the operators.
- Guide rollers are with double ball bearings, offering smooth motion to the conveyor.
- Special tablet dust filter mesh is provided at the vibrator.
- Dust collecting tray with cleaning brush is also provided below the conveyor.
Description
Technical Specification:
| Model | BEW |
| Motor | 1⁄4 HP, 220 Volts, 1 Phase, 50 Hz |
| Gear Box | 40:1 |
| Inspection Belt | Nylon Endless |
| Hopper | Round Conical Hopper 18″ Dia. |
| Dimension of the Machine (mm) (L x W x H) | 2000 x 370 x 1400 |
| Drive | V belt Drive |
| All Contact Parts | Stainless Steel 316 Quality |
| Inspection | Both sides of the tablet can be inspected. |
